1. Product Features
1. This product is a two-component structural adhesive with high temperature resistance and high strength;
2. It can be quickly cured at room temperature to achieve fast bonding and fixing;
3. Good adhesion to various materials such as glass, metal, ceramics, PC, PBT, etc., and non-corrosive to the substrate;
4. Has excellent electrical properties and chemical weather resistance;
2. Main use
1. Fast bonding of lighting product components, fixing of circuit board components, etc.;
2. Other parts that require quick bonding.
3. Technical data
Test items | Test results |
Before curing | |
Color (A/B) | White/colorless or light yellow haze transparent |
Extrusion ratio A:B | 1:1 |
Initial solidification time (5g glue/25℃, min) | 5~10 |
Pot life (5g glue/25℃, min) | 2 |
After curing | |
Colour | White or light yellow |
Density (g/cm3) | 1.2-1.3 |
Shear Strength (Al to Al, MPa) | ≥10 |
Dielectric Strength (kV/mm) | 20 |
4. How to use
1. Before gluing, remove all grease and stains that affect the bonding, and ensure that the bonded surface is clean, dry and free of dirt.
2. Install the glue cartridge on the glue gun, open the sealing rubber stopper and dispense a portion of the glue until the two-component rubber stopper is flush.
3. Install a suitable mixing nozzle on the rubber barrel, squeeze out some glue until the AB glue is mixed evenly.
4. Apply glue to the substrate.
5. Storage conditions
Store in a cool, dry, well-ventilated area away from sources of ignition and incompatible materials. The shelf life is 12 months. Products that exceed the shelf life can be used within one month after inspection, and the technical indicators are still qualified.
6. Matters needing attention
irritating. May be harmful if swallowed or inhaled. In case of contact with eyes, flush with water for at least 15 to 20 minutes. In case of contact with skin, immediately rinse skin with water and soap for 15 to 20 minutes. If inhaled, remove patient to fresh air. If swallowed, do not induce vomiting, seek medical attention immediately. Keep out of reach of children. It is recommended to use at 25 ± 3°C, and it is not recommended to use below 15°C or above 35°C.
